CSE185L - Triad Magnetics

CSE185L Details

• Manufacturer Part Number:

  CSE185L

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Manufacturer:

  Triad Magnetics

• YTEOL:

  8

• Application:

  POWER

• Approvals:

  UL

• ET Product-Min:

  30000 V-us

• Height:

  18 mm

• Input Voltage-Max:

  240 V

• Isolation Voltage:

  2500 V

• Length:

  24 mm

• Load Resistance:

  0.023 Ω

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  1

• Operating Frequency-Max:

  0.4 kHz

• Operating Frequency-Min:

  0.05 kHz

• Operating Temperature-Max:

  95 °C

• Operating Temperature-Min:

  -30 °C

• Output Voltage 1:

  4 V

• Primary Type:

  WOUND PRIMARY

• Surface Mount:

  NO

• Transformer Type:

  CURRENT SENSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:50

• Width:

  21.5 mm
