CST2010-020LD - COILCRAFT

CST2010-020LD Details

• Manufacturer Part Number:

  CST2010-020LD

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  8

• Approvals:

  AEC-Q200

• ET Product-Min:

  50.8 V-us

• Height:

  10.5 mm

• Length:

  14.55 mm

• Load Resistance:

  0.5 Ω

• Mounting Feature:

  SURFACE MOUNT

• Operating Frequency-Max:

  1000 kHz

• Operating Frequency-Min:

  10 kHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, EMBOSSED PLASTIC, 13 INCH

• Peak Primary Current:

  47 A

• Primary Type:

  WOUND PRIMARY

• Secondary Inductance:

  340 µH

• Surface Mount:

  YES

• Transformer Type:

  CURRENT SENSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:20

• Width:

  13 mm
