CT1102V3.15F160 - CIT Relay & Switch

CT1102V3.15F160 Details

• Manufacturer Part Number:

  CT1102V3.15F160

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  CIT Relay & Switch

• Actuator Material:

  POLYAMIDE66

• Actuator Travel:

  0.25 mm

• Body Breadth:

  6.3 mm

• Body Height:

  7.2 mm

• Body Length or Diameter:

  7.5 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  SILVER

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  .05A@50VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  50 V

• Dielectric Withstand Volts:

  250VRMS V

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  SILVER

• Housing Material:

  NYLON66

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Switches:

  1

• Operating Force-Max:

  2.059 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  4

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Finish:

  SILVER

• Terminal Length:

  0.138 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
