CT94F-100M-H - Central Technologies

CT94F-100M-H Details

• Manufacturer Part Number:

  CT94F-100M-H

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Central Technologies

• YTEOL:

  5.7

• Construction:

  Toroidal

• Core Material:

  IRON-FERRITE

• Inductance-Nom (L):

  10 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Diameter:

  27.9 mm

• Package Length:

  12.7 mm

• Package Style:

  Toroidal

• Packing Method:

  Bulk

• Rated Current-Max:

  5 A

• Shape/Size Description:

  DISK PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  20%
