CU-18PMMP-LC7001 - Amphenol

CU-18PMMP-LC7001 Frequently Asked Questions (FAQs)

• What is the recommended torque for the connectors?
  The recommended torque for the CU-18PMMP-LC7001 connectors is 10-12 in-lbs (1.1-1.4 Nm) for the plug and 12-15 in-lbs (1.4-1.7 Nm) for the receptacle.
• Can I use this connector in high-vibration applications?
  Yes, the CU-18PMMP-LC7001 is designed to withstand high-vibration environments. It meets the vibration requirements of MIL-DTL-38999, which includes sinusoidal vibration testing at 20 Gs peak acceleration.
• Is this connector suitable for use in harsh environments, such as high-temperature or high-humidity applications?
  Yes, the CU-18PMMP-LC7001 is designed to operate in harsh environments. It has a temperature range of -65°C to 200°C and can withstand humidity up to 95% RH at 40°C.
• What is the mating cycle life of the connector?
  The CU-18PMMP-LC7001 has a mating cycle life of 500 cycles minimum, making it suitable for applications that require frequent mating and unmating.
• Can I use this connector with other manufacturers' mating components?
  It is recommended to use the CU-18PMMP-LC7001 with Amphenol's mating components to ensure compatibility and optimal performance. However, it may be possible to use it with other manufacturers' components that meet the same MIL-DTL-38999 specifications, but compatibility should be verified through testing and validation.
