CY15B104Q-PZXI - Infineon

CY15B104Q-PZXI Details

• Manufacturer Part Number:

  CY15B104Q-PZXI

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  3

• Additional Feature:

  DATA RETENTION TIME @ 85 DEGREE CENTIGRADE

• Clock Frequency-Max (fCLK):

  40 MHz

• Data Retention Time-Min:

  10

• Endurance:

  1000000000000000 Write/Erase Cycles

• JESD-30 Code:

  R-PDIP-T8

• Length:

  9.779 mm

• Memory Density:

  4194304 bit

• Memory IC Type:

  FRAM

• Memory Width:

  8

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Number of Words:

  524288 words

• Number of Words Code:

  512000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  512KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP8,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Parallel/Serial:

  SERIAL

• Seated Height-Max:

  4.572 mm

• Serial Bus Type:

  SPI

• Standby Current-Max:

  0.00007 A

• Standby Voltage-Min:

  1.8 V

• Supply Current-Max:

  0.003 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  1.8 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm

• Write Protection:

  HARDWARE/SOFTWARE
