CY7C65213-32LTXIT - Infineon

CY7C65213-32LTXIT Details

• Manufacturer Part Number:

  CY7C65213-32LTXIT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A991.B.2.B

• HTS Code:

  8542.31.00.01

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  6

• Additional Feature:

  ALSO OPERATES AT 3.3 V TYP

• Bus Compatibility:

  UART; VBUS

• Clock Frequency-Max:

  48 MHz

• Data Transfer Rate-Max:

  1.5 MBps

• Drive Interface Standard:

  RS232; RS422; RS485

• JESD-30 Code:

  S-XQCC-N32

• JESD-609 Code:

  e4

• Length:

  5 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  32

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC32,.2SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  18 mA

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  3.15 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  5 mm

• uPs/uCs/Peripheral ICs Type:

  BUS CONTROLLER, UNIVERSAL SERIAL BUS
