CY7C65215A-32LTXI - Infineon

CY7C65215A-32LTXI Details

• Manufacturer Part Number:

  CY7C65215A-32LTXI

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A991.B.2.B

• HTS Code:

  8542.31.00.01

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  7.45

• Additional Feature:

  ALSO OPERATES AT 2V-5.5V SUPPLY RANGE.

• Bus Compatibility:

  I2C; SPI; UART; VBUS

• Clock Frequency-Max:

  48 MHz

• Data Transfer Rate-Max:

  1.5 MBps

• Drive Interface Standard:

  RS232; RS422; RS485

• JESD-30 Code:

  S-XQCC-N32

• JESD-609 Code:

  e3

• Length:

  5 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  32

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  1 mm

• Supply Voltage-Max:

  1.89 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Pure Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  5 mm

• uPs/uCs/Peripheral ICs Type:

  BUS CONTROLLER, UNIVERSAL SERIAL BUS
