CY8C20236A-24LKXI - Infineon

Description: CY8C20xx6A_S

Download CY8C20236A-24LKXI Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
CY8C20236A-24LKXI - Infineon PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 16-pin Chip On Lead (3 × 3 × 0.6 mm) LG16A/LD16A (Sawn) Package Outline, 001-09116_1
click to zoom
3D Models
CY8C20236A-24LKXI - Infineon  - 3D model - Quad Flat No-Lead - 16-pin Chip On Lead (3 × 3 × 0.6 mm) LG16A/LD16A (Sawn) Package Outline, 001-09116_1
click to zoom

CY8C20236A-24LKXI Details

  • Manufacturer Part Number:

    CY8C20236A-24LKXI

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFN-16

  • Similar Group:

    MC001004116511811531

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    10

  • JESD-30 Code:

    S-XQCC-N16

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VQCCN

  • Package Equivalence Code:

    LCC16,.12SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    0.6 mm

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    1.71 V

  • Supply Voltage-Nom:

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

  • uPs/uCs/Peripheral ICs Type:

    PROGRAMMABLE SoC

CY8C20236A-24LKXI Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for CY8C20236A-24LKXI is 1.71V to 5.5V, with a typical voltage of 3.3V.
  • The clock source for CY8C20236A-24LKXI can be configured using the Clock Control Register (CLK_CR). You can choose between internal oscillator, external crystal oscillator, or external clock source.
  • The maximum frequency of the CPU clock for CY8C20236A-24LKXI is 24 MHz.
  • CY8C20236A-24LKXI has several low-power modes, including Sleep, Hibernate, and Stop modes. These modes can be implemented using the Power Mode Control Register (PMC) and the Sleep Timer Register (STMR).
  • The maximum current consumption of CY8C20236A-24LKXI is approximately 20 mA at 24 MHz, 3.3V, and room temperature.
