CY8C20766A-24FDXCT - Infineon

CY8C20766A-24FDXCT Details

• Manufacturer Part Number:

  CY8C20766A-24FDXCT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  WLCSP-30

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  Infineon Technologies AG

• Bit Size:

  8

• Boundary Scan:

  NO

• Bus Compatibility:

  USB

• CPU Family:

  M8C

• Clock Frequency-Max:

  25.2 MHz

• JESD-30 Code:

  R-PBGA-B30

• JESD-609 Code:

  e1

• Length:

  2.32 mm

• Number of I/O Lines:

  27

• Number of Terminals:

  30

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA30,5X6,14

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Qualification Status:

  Not Qualified

• RAM (bytes):

  2048

• RAM (words):

  1024

• ROM (words):

  32768

• ROM Programmability:

  FLASH

• Seated Height-Max:

  0.4 mm

• Supply Current-Max:

  4 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN SILVER COPPER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.38 mm

• Terminal Position:

  BOTTOM

• Width:

  2.2 mm
