CY8C4045PVS-S412 - Infineon

Description: ARM Microcontrollers - MCU PSoC4

Download CY8C4045PVS-S412 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
CY8C4045PVS-S412 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - 28-Pin SSOP_
click to zoom
3D Models
CY8C4045PVS-S412 - Infineon  - 3D model - Small Outline Packages - 28-Pin SSOP_
click to zoom

CY8C4045PVS-S412 Details

  • Manufacturer Part Number:

    CY8C4045PVS-S412

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • HTS Code:

    8542.31.00.30

  • Factory Lead Time:

    26 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    13

  • JESD-30 Code:

    R-PDSO-G28

  • JESD-609 Code:

    e4

  • Length:

    10.2 mm

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    28

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SSOP

  • Package Equivalence Code:

    SSOP28,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, SHRINK PITCH

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    2 mm

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    1.8 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    5.3 mm

  • uPs/uCs/Peripheral ICs Type:

    PROGRAMMABLE SoC

CY8C4045PVS-S412 Frequently Asked Questions (FAQs)

  • The recommended crystal oscillator frequency for the CY8C4045PVS-S412 is 32.768 kHz. This frequency is used as the clock source for the internal real-time clock (RTC) and watchdog timer.
  • The GPIO pins on the CY8C4045PVS-S412 can be configured as analog or digital inputs using the Pin Configuration Register (PCR). The PCR register is used to set the pin mode, drive mode, and input buffer mode for each GPIO pin.
  • The maximum current that can be sourced or sunk by the GPIO pins on the CY8C4045PVS-S412 is 25 mA. However, the total current sourced or sunk by all GPIO pins should not exceed 150 mA to ensure reliable operation.
  • The internal voltage regulator on the CY8C4045PVS-S412 can be used to power external components by connecting the VREG pin to the external component's power pin. The internal voltage regulator can supply up to 50 mA of current to external components.
  • The VBAT pin on the CY8C4045PVS-S412 is used to connect a battery or a supercapacitor to the microcontroller. The VBAT pin is used to power the internal real-time clock (RTC) and other internal circuits when the main power supply is turned off.
