CY95F633KPMC-G-UNE2 - Infineon

CY95F633KPMC-G-UNE2 Details

• Manufacturer Part Number:

  CY95F633KPMC-G-UNE2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Has ADC:

  YES

• Additional Feature:

  IN ON-CHIP DEBUG MODE MINIMUN VOLTAGE WILL BE 2.88V AND TEMPERATURE RANGE IS 5 TO 35 DEGREE CELCIUS

• Bit Size:

  8

• Boundary Scan:

  NO

• Clock Frequency-Max:

  32.5 MHz

• DAC Channels:

  NO

• DMA Channels:

  NO

• JESD-30 Code:

  S-PQFP-G32

• JESD-609 Code:

  e3

• Length:

  7 mm

• Number of I/O Lines:

  29

• Number of Terminals:

  32

• On Chip Program ROM Width:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PWM Channels:

  YES

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, LOW PROFILE

• RAM (bytes):

  512

• ROM (words):

  12288

• ROM Programmability:

  FLASH

• Seated Height-Max:

  1.6 mm

• Speed:

  16.25 MHz

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  QUAD

• Width:

  7 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER
