D2A050000 - Cosmo

D2A050000 Details

• Manufacturer Part Number:

  D2A050000

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Cosmo Electronics

• Body Breadth:

  7 mm

• Body Height:

  5.5 mm

• Body Length or Diameter:

  19.5 mm

• Coil Current(DC)-Max:

  0.036 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  180 mW

• Coil Release Voltage(DC):

  1 V

• Coil Resistance:

  140 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  .5A@200VDC

• Contact Voltage(DC)-Max:

  200 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  100000000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  1 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  19.5mm x 7mm x 5.5mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Function:

  DPST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.7 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
