DAC904E - BURR-BROWN

DAC904E Details

• Manufacturer Part Number:

  DAC904E

• Rohs Code:

  No

• Part Life Cycle Code:

  Transferred

• Package Description:

  TSSOP, TSSOP28,.25

• Reach Compliance Code:

  Unknown

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Burr-Brown Corp

• Analog Output Voltage-Max:

  5.5 V

• Analog Output Voltage-Min:

  2.7 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  PARALLEL, WORD

• JESD-30 Code:

  R-PDSO-G28

• JESD-609 Code:

  e0

• Linearity Error-Max (EL):

  0.0153%

• Number of Bits:

  14

• Number of Functions:

  1

• Number of Terminals:

  28

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP28,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Settling Time-Nom (tstl):

  0.03 µs

• Supply Current-Max:

  30 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.635 mm

• Terminal Position:

  DUAL
