DAQ0150V2PBC - Murata Electronics

DAQ0150V2PBC Details

• Manufacturer Part Number:

  DAQ0150V2PBC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  1/4 BRICK PACKAGE-15

• ECCN Code:

  EAR99

• Factory Lead Time:

  38 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  96%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDIP-P15

• Length:

  58.42 mm

• Line Regulation-Max:

  0.625%

• Load Regulation-Max:

  0.375%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  15

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  50 A

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIP

• Package Equivalence Code:

  DIP15,2(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  13.208 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  600 W

• Trim/Adjustable Output:

  YES

• Width:

  36.83 mm
