DAT-15R5-PP+ - Mini-Circuits

DAT-15R5-PP+ Details

• Manufacturer Part Number:

  DAT-15R5-PP+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  4 X 4 MM, ROHS COMPLIANT, CASE DG983-1, 20 PIN

• Manufacturer:

  Mini-Circuits

• YTEOL:

  3

• Attenuation-Nom:

  15.5 dB

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  23.98 dBm

• Insertion Loss-Max:

  4.7 dB

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  20

• Operating Frequency-Max:

  4000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC20,.16SQ,20

• Power Supplies:

  3 V

• RF/Microwave Device Type:

  VARIABLE ATTENUATOR

• Supply Current-Max:

  0.1 mA

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Matte Tin (Sn)

• VSWR-Max:

  2.1
