DC1390R-154K - API Delevan

DC1390R-154K Details

• Manufacturer Part Number:

  DC1390R-154K

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  API Delevan

• YTEOL:

  0

• Construction:

  Cylindrical

• DC Resistance:

  0.04 Ω

• Inductance-Nom (L):

  150 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e2

• Lead Diameter:

  1.4478 mm

• Lead Length:

  19.05 mm

• Lead Spacing:

  29.21 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  37.6 mm

• Package Length:

  27.03 mm

• Package Style:

  Radial

• Packing Method:

  Bulk

• Rated Current-Max:

  7.72 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Copper (Sn99.3Cu0.7)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  10%
