DC2327J5005AHF - ANAREN

Description: Signal Conditioning 2300-2700MHz IL .4dB Mn Coupling 5.5dB

Download DC2327J5005AHF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DC2327J5005AHF - ANAREN - PCB symbol
click to zoom
PCB Footprints
DC2327J5005AHF - ANAREN PCB footprint - Other - Other - DC2327J5005AHF-2
click to zoom
3D Models
DC2327J5005AHF - ANAREN - 3D model - Other - DC2327J5005AHF-2
click to zoom

DC2327J5005AHF Details

  • Manufacturer Part Number:

    DC2327J5005AHF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Transferred

  • Manufacturer:

    Anaren Microwave

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    33.01 dBm

  • Insertion Loss-Max:

    0.4 dB

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    2700 MHz

  • Operating Frequency-Min:

    2300 MHz

  • Operating Temperature-Max:

    140 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Equivalence Code:

    SOLCC6,.05,25

  • RF/Microwave Device Type:

    DIRECTIONAL COUPLER

  • Surface Mount:

    YES

  • Terminal Finish:

    Gold (Au) - with Nickel (Ni) barrier

  • VSWR-Max:

    1.22

DC2327J5005AHF Frequently Asked Questions (FAQs)

  • The recommended PCB layout and land pattern can be found in the Anaren Microwave application note AN-112, which provides guidelines for optimal PCB design and layout for the DC2327J5005AHF.
  • The DC2327J5005AHF has a thermal pad on the bottom of the package, which should be connected to a thermal ground plane on the PCB to dissipate heat. Additionally, a thermal interface material (TIM) can be used to improve heat transfer between the device and the PCB.
  • The DC2327J5005AHF is rated for operation from -40°C to +85°C, but it's recommended to derate the power handling at higher temperatures to ensure reliable operation.
  • The DC2327J5005AHF has a nominal impedance of 50 ohms, but the actual impedance may vary depending on the frequency and application. Anaren Microwave provides a set of recommended matching circuits and component values in the datasheet and application notes to help achieve optimal impedance matching.
  • The DC2327J5005AHF is rated for a maximum input power of 5W, but the actual power handling may be limited by the application and operating conditions. It's recommended to consult the datasheet and application notes for specific power handling guidelines.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

DC2327J5005AHF Overview

Use the download button to access the DC2327J5005AHF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like DC232, or try a keyword search, such as RF/Microwave Couplers
