DCM3623T50M26C2T00 - VICOR

DCM3623T50M26C2T00 Details

• Manufacturer Part Number:

  DCM3623T50M26C2T00

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-9

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Date Of Intro:

  2016-10-12

• Manufacturer:

  Vicor Corporation

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, EN, TUV, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  91.9%

• Input Voltage-Max:

  50 V

• Input Voltage-Min:

  16 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-XDMA-P9

• JESD-609 Code:

  e4

• Length:

  38.72 mm

• Load Regulation-Max:

  5.82%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  95 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  13.4 A

• Output Voltage-Max:

  26.4 V

• Output Voltage-Min:

  14.4 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Ripple Voltage (Main Out):

  0.260883 Vrms

• Seated Height-Max:

  7.31 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  320 W

• Trim/Adjustable Output:

  YES

• Width:

  22.8 mm
