DCM3717S60E14G5TN0 - VICOR

DCM3717S60E14G5TN0 Details

• Manufacturer Part Number:

  DCM3717S60E14G5TN0

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-15

• ECCN Code:

  EAR99

• Manufacturer:

  Vicor Corporation

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE

• Efficiency (Main Output):

  97%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  40 V

• Input Voltage-Nom:

  54 V

• JESD-30 Code:

  R-XQMA-N15

• Length:

  36.7 mm

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  0.2%

• Moisture Sensitivity Level:

  4

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  15

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  62.5 A

• Output Voltage-Max:

  13.5 V

• Output Voltage-Min:

  10 V

• Output Voltage-Nom:

  12.2 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  QMA

• Package Equivalence Code:

  MODULE,15LEAD(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  245

• Protections:

  THERMAL

• Ripple Voltage (Main Out):

  0.09898 Vrms

• Seated Height-Max:

  7.542 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Form:

  NO LEAD

• Terminal Position:

  QUAD

• Total Power Output-Max:

  750 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.016 s

• Width:

  17.34 mm
