DCM4623TD2N31C8T70 - VICOR

DCM4623TD2N31C8T70 Details

• Manufacturer Part Number:

  DCM4623TD2N31C8T70

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP PACKAGE-9

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Date Of Intro:

  2020-01-29

• Manufacturer:

  Vicor Corporation

• YTEOL:

  9.1

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  93.9%

• Input Voltage-Max:

  420 V

• Input Voltage-Min:

  120 V

• Input Voltage-Nom:

  275 V

• JESD-30 Code:

  R-XDMA-T9

• Length:

  47.91 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  13.4 A

• Output Voltage-Max:

  30.8 V

• Output Voltage-Min:

  16.8 V

• Output Voltage-Nom:

  28 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  UNDER VOLTAGE, OVER VOLTAGE, OVER CURRENT, SHORT CIRCUIT, THERMAL

• Ripple Voltage (Main Out):

  0.26759 Vrms

• Seated Height-Max:

  7.31 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Total Power Output-Max:

  375 W

• Trim/Adjustable Output:

  YES

• Width:

  22.8 mm
