DCU0-1209D Details

• Manufacturer Part Number:

  DCU0-1209D

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-23

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  Halo Electronics Inc

• YTEOL:

  1

• Additional Feature:

  LG-MAX

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  12 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-PDIP-T23

• Length:

  32.766 mm

• Load Regulation-Max:

  15%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  23

• Operating Temperature-Max:

  70 °C

• Output Current-Max:

  0.25 A

• Output Voltage-Max:

  9.45 V

• Output Voltage-Min:

  8.55 V

• Output Voltage-Nom:

  9 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP23/24,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  12.065 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  2 W

• Trim/Adjustable Output:

  NO

• Width:

  15.24 mm
