DDB2U20N12W1RFB11BPSA1 - Infineon

DDB2U20N12W1RFB11BPSA1 Details

• Manufacturer Part Number:

  DDB2U20N12W1RFB11BPSA1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  MODULE-6

• Country Of Origin:

  Germany

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  7

• Additional Feature:

  IR-NOM

• Case Connection:

  ISOLATED

• Configuration:

  BRIDGE, 4 ELEMENTS WITH BUILT-IN THERMISTOR

• Diode Element Material:

  SILICON CARBIDE

• Diode Type:

  BRIDGE RECTIFIER DIODE

• JESD-30 Code:

  R-XUFM-X6

• Non-rep Pk Forward Current-Max:

  150 A

• Number of Elements:

  4

• Number of Phases:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Reference Standard:

  IEC-60747; IEC-60749; IEC-60068; IEC-61140

• Rep Pk Reverse Voltage-Max:

  1200 V

• Reverse Current-Max:

  58 µA

• Reverse Test Voltage:

  1200 V

• Surface Mount:

  NO

• Technology:

  SCHOTTKY

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER
