DDRH-30-48P - Mean Well

DDRH-30-48P Details

• Manufacturer Part Number:

  DDRH-30-48P

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-5

• ECCN Code:

  EAR99

• Manufacturer:

  Mean Well

• YTEOL:

  9

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  BS, CSA, EAC, EN, IEC, UL

• Efficiency (Main Output):

  91%

• Input Voltage-Max:

  1500 V

• Input Voltage-Min:

  150 V

• Input Voltage-Nom:

  800 V

• JESD-30 Code:

  R-PXMA-P5

• JESD-609 Code:

  e3

• Length:

  89 mm

• Line Regulation-Max:

  1%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.625 A

• Output Voltage-Max:

  48.96 V

• Output Voltage-Min:

  47.04 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  PLASTIC

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,5LEAD,3.1

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVERLOAD, OVER VOLTAGE, REVERSE POLARITY, UNDER VOLTAGE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.053025 Vrms

• Seated Height-Max:

  25.7 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  30 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  2 s

• Width:

  63.5 mm
