DETN02L-05 - Mean Well

DETN02L-05 Details

• Manufacturer Part Number:

  DETN02L-05

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD-12/10

• ECCN Code:

  EAR99

• Factory Lead Time:

  19 Weeks, 3 Days

• Manufacturer:

  Mean Well

• YTEOL:

  6

• Additional Feature:

  -5V OUTPUT AVAILABLE, ALSO AVAILA BLE IN TR PACKAGE

• Analog IC - Other Type:

  DC-DC UNREGULATED POWER SUPPLY MODULE

• Approvals:

  BS, CE, EAC, EN, UL

• Efficiency (Main Output):

  78%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-PDMA-G10

• Length:

  15.24 mm

• Line Regulation-Max:

  1.2%

• Load Regulation-Max:

  8%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  10

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.2 A

• Output Voltage-Max:

  5.1 V

• Output Voltage-Min:

  4.9 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,10/12LEAD,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  240

• Protections:

  SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.02651 Vrms

• Seated Height-Max:

  7.6 mm

• Surface Mount:

  YES

• Switching Frequency-Max:

  100 kHz

• Technology:

  HYBRID

• Terminal Form:

  GULL WING

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Total Power Output-Max:

  2 W

• Trim/Adjustable Output:

  NO

• Width:

  10.7 mm
