DF10G5M4N,LF - Toshiba

DF10G5M4N,LF Details

• Manufacturer Part Number:

  DF10G5M4N,LF

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN10, 10 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  6

• Breakdown Voltage-Max:

  6 V

• Breakdown Voltage-Min:

  4 V

• Breakdown Voltage-Nom:

  5 V

• Clamping Voltage-Max:

  15 V

• Configuration:

  COMMON ANODE, 5 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-N10

• Non-rep Peak Rev Power Dis-Max:

  30 W

• Number of Elements:

  5

• Number of Terminals:

  10

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity:

  BIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-2, 4-5

• Rep Pk Reverse Voltage-Max:

  3.6 V

• Reverse Current-Max:

  0.1 µA

• Reverse Test Voltage:

  3.6 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
