The recommended mating sequence is to insert the plug into the receptacle while aligning the keyways, then rotate the plug clockwise to secure it. This ensures proper connection and prevents damage to the contacts.
To ensure reliable connections in high-vibration environments, it's recommended to use a secure locking mechanism, such as a screw lock or a latch, to prevent the connector from coming loose. Additionally, applying a small amount of contact lubricant can help reduce wear and tear on the contacts.
The maximum operating temperature range for the DF3A-14P-2DSA connector is -40°C to +105°C. However, it's essential to note that the connector's performance and reliability may degrade at extreme temperatures, so it's recommended to consult the datasheet and application notes for specific temperature-related guidelines.
The DF3A-14P-2DSA connector is designed to operate in normal environments, but it may not be suitable for harsh environments with high humidity or exposure to chemicals. For such applications, it's recommended to use connectors with specialized coatings or sealing, such as Hirose's waterproof or hermetically sealed connectors.
The recommended torque value for the DF3A-14P-2DSA connector's screw lock is 0.5 N·m to 1.5 N·m. Over-tightening can damage the connector, so it's essential to follow the recommended torque specification.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
DF3A-14P-2DSA Overview
Use the download button to access the DF3A-14P-2DSA schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like DF3A-,
or try a keyword search, such as Headers and Edge Type Connectors
