DF52-20S-0.8H - Hirose

DF52-20S-0.8H Details

• Manufacturer Part Number:

  DF52-20S-0.8H

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Hirose Electric Co Ltd

• YTEOL:

  7

• Body Breadth:

  0.069 inch

• Body Depth:

  0.161 inch

• Body Length:

  0.716 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  TIN

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  10 mΩ

• Contact Style:

  SQ PIN-SKT

• Dielectric Withstanding Voltage:

  300VAC V

• Durability:

  20 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYAMIDE

• Mating Contact Pitch:

  0.031 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  CABLE

• Number Of Connectors:

  ONE

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Rated Current (Power):

  1.2 A

• Reference Standard:

  UL

• Terminal Pitch:

  0.8 mm

• Termination Type:

  CRIMP

• Total Number of Contacts:

  20

• UL Flammability Code:

  94V-0

• Wire Size-Max:

  28 AWG

• Wire Size-Min:

  28 AWG
