DHG55I3300FE - LITTELFUSE

DHG55I3300FE Details

• Manufacturer Part Number:

  DHG55I3300FE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  5.75

• Additional Feature:

  FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE

• Application:

  FAST SOFT RECOVERY

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  3.4 V

• JESD-30 Code:

  R-PSFM-T2

• Non-rep Pk Forward Current-Max:

  600 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  50 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Packing Method:

  TUBE

• Power Dissipation-Max:

  280 W

• Rep Pk Reverse Voltage-Max:

  3300 V

• Reverse Current-Max:

  100 µA

• Reverse Recovery Time-Max:

  1.65 µs

• Reverse Test Voltage:

  3300 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE
