DIL12-2C90-63L - Meder

DIL12-2C90-63L Details

• Manufacturer Part Number:

  DIL12-2C90-63L

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Germany

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Standex-Meder Electronics

• YTEOL:

  8.3

• Body Breadth:

  10.2 mm

• Body Height:

  10.2 mm

• Body Length or Diameter:

  20.1 mm

• Coil Current(DC)-Max:

  0.016 A

• Coil Operate Voltage(DC):

  8.4 V

• Coil Power:

  211 mW

• Coil Release Voltage(DC):

  1.8 V

• Coil Resistance:

  748 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .25A@175VAC

• Contact Current(AC)-Max:

  0.25 A

• Contact Current(DC)-Max:

  0.25 A

• Contact (DC) Max Rating R Load:

  .25A@175VDC

• Contact Voltage(AC)-Max:

  175 V

• Contact Voltage(DC)-Max:

  175 V

• Contact/Output Supply Type:

  AC/DC

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  1 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Physical Dimension:

  20.1mm x 10.2mm x 10.2mm

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  DRY REED RELAY

• Release Time:

  1.5 ms

• Surface Mount:

  NO

• Terminal Finish:

  TIN

• Termination Type:

  SOLDER
