DIP05-1C90-51L - STANDEXMEDER

DIP05-1C90-51L Details

• Manufacturer Part Number:

  DIP05-1C90-51L

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Germany

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Standex-Meder Electronics

• YTEOL:

  6.95

• Additional Feature:

  LOW PROFILE

• Body Height:

  5.1 mm

• Body Length or Diameter:

  19.3 mm

• Coil Current(DC)-Max:

  0.034 A

• Coil Operate Voltage(DC):

  3.5 V

• Coil Power:

  125 mW

• Coil Release Voltage(DC):

  0.75 V

• Coil Resistance:

  220 Ω

• Coil Voltage(DC)-Max:

  7.5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.2A@100VAC

• Contact Current(AC)-Max:

  0.2 A

• Contact Current(DC)-Max:

  0.2 A

• Contact (DC) Max Rating R Load:

  0.2A@100VDC

• Contact Resistance:

  200 mΩ

• Contact Voltage(AC)-Max:

  100 V

• Contact Voltage(DC)-Max:

  100 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000000 Cycle(s)

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  2 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TUBE

• Physical Dimension:

  19.3mm x 6.4mm x 5.1mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  DRY REED RELAY

• Release Time:

  2 ms

• Surface Mount:

  NO

• Terminal Length:

  0.003200406400812802 inch

• Termination Type:

  SOLDER
