DIP1-1B12 - Teledyne Technologies

DIP1-1B12 Details

• Manufacturer Part Number:

  DIP1-1B12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  7.99

• Additional Feature:

  SOCKET MOUNTABLE

• Body Breadth:

  6.88 mm

• Body Height:

  5.51 mm

• Body Length or Diameter:

  19.91 mm

• Coil Current(DC)-Max:

  0.012 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  144 mW

• Coil Release Voltage(DC):

  1 V

• Coil Resistance:

  1000 Ω

• Coil Voltage(DC)-Max:

  14.5 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.5A@100VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  0.5A@100VDC

• Contact Resistance:

  150 mΩ

• Contact Voltage(AC)-Max:

  100 V

• Contact Voltage(DC)-Max:

  100 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  1000000 Cycle(s)

• End Contact Material:

  Rhodium

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  1 ms

• Operating Frequency-Max:

  0.0002 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  19.91mm x 6.88mm x 5.51mm

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM B

• Relay Function:

  SPST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.05 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Length:

  0.003098806197612395 inch

• Termination Type:

  SOLDER
