DKMW06F-24 - Mean Well

Description: Isolated DC/DC Converters 6W 9-36Vin +/-24V +/-125mA DIP 1x1 Reg

Download DKMW06F-24 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DKMW06F-24 - Mean Well - PCB symbol
click to zoom
PCB Footprints
DKMW06F-24 - Mean Well PCB footprint - Other - Other - DKMW06F-24-2
click to zoom
3D Models
DKMW06F-24 - Mean Well - 3D model - Other - DKMW06F-24-2
click to zoom

DKMW06F-24 Details

  • Manufacturer Part Number:

    DKMW06F-24

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mean Well

  • YTEOL:

    0

  • Analog IC - Other Type:

    DC-DC REGULATED POWER SUPPLY MODULE

DKMW06F-24 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the DKMW06F-24 is -20°C to 60°C, with a derating of 2.5% per °C above 40°C.
  • Yes, the DKMW06F-24 is designed to operate in humid environments, but it's recommended to keep the relative humidity below 90% to prevent condensation.
  • The minimum load requirement for the DKMW06F-24 is 0A, but it's recommended to have a minimum load of 10% to 20% of the maximum output current to ensure stable operation.
  • Yes, you can parallel multiple DKMW06F-24 units, but it's recommended to use a master-slave configuration and ensure that the output voltage and current are matched to prevent instability.
  • The MTBF of the DKMW06F-24 is approximately 550,000 hours at 25°C, calculated according to MIL-HDBK-217F.
