DLD101-7 - Diodes Incorporated

Description: DiodesZetex DLD101-7, LED Display Driver LED Driver IC 1 Output Linear PWM Dimming 1A DFN3030D-8

Download DLD101-7 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
DLD101-7 - Diodes Incorporated PCB footprint - Other - Other - DFN3030D-8
click to zoom
3D Models
DLD101-7 - Diodes Incorporated  - 3D model - Other - DFN3030D-8
click to zoom

DLD101-7 Details

  • Manufacturer Part Number:

    DLD101-7

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DFN

  • Package Description:

    3 X 3 MM, GREEN, PLASTIC, DFN-8

  • Pin Count:

    8

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    8

  • Interface IC Type:

    LED DISPLAY DRIVER

  • JESD-30 Code:

    S-PDSO-N8

  • JESD-609 Code:

    e4

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    1

  • Multiplexed Display Capability:

    NO

  • Number of Functions:

    1

  • Number of Segments:

    1

  • Number of Terminals:

    8

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC8,.12,25

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Screening Level:

    AEC-Q101

  • Seated Height-Max:

    0.63 mm

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Terminal Finish:

    NICKEL PALLADIUM GOLD

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

DLD101-7 Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for the DLD101-7 is -40°C to 125°C.
  • To ensure proper soldering, follow the recommended soldering profile and use a solder with a melting point above 217°C. Also, ensure the PCB is designed with a suitable thermal relief pattern.
  • The maximum allowable voltage for the DLD101-7 is 100V. Exceeding this voltage may damage the device.
  • Yes, the DLD101-7 is suitable for high-frequency switching applications up to 100 kHz. However, ensure proper PCB design and layout to minimize parasitic inductance and capacitance.
  • To prevent ESD damage, handle the DLD101-7 with an anti-static wrist strap or mat, and ensure the workspace is ESD-protected. Avoid touching the device's pins or leads.
