DLF-28-0006 - SCHURTER

DLF-28-0006 Details

• Manufacturer Part Number:

  DLF-28-0006

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Schurter Electronic Components

• YTEOL:

  0

• Construction:

  Rectangular

• DC Resistance:

  0.07 Ω

• Inductance-Nom (L):

  100 µH

• Inductor Application:

  DC-DC CONVERTER

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Length:

  3.5 mm

• Number of Functions:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  16.5 mm

• Package Length:

  28.3 mm

• Package Style:

  PCB Mount

• Package Width:

  27.4 mm

• Rated Current-Max:

  3 A

• Self Resonance Frequency:

  7.5 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  FLAT

• Tolerance:

  15%
