DMF05LCFLP-7 - Diodes Incorporated

Description: ESD Suppressors / TVS Diodes ESD PRO DIODE ARRAY 70W5.0V

Download DMF05LCFLP-7 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
DMF05LCFLP-7 - Diodes Incorporated PCB footprint - Small Outline No-lead - Small Outline No-lead - DMF05LCFLP-7
click to zoom
3D Models
DMF05LCFLP-7 - Diodes Incorporated  - 3D model - Small Outline No-lead - DMF05LCFLP-7
click to zoom

DMF05LCFLP-7 Details

  • Manufacturer Part Number:

    DMF05LCFLP-7

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    DFN

  • Package Description:

    1.60 X 1.60 MM, GREEN, PLASTIC, DFN1616-6, 6 PIN

  • Pin Count:

    6

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.10.00.50

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    0

  • Additional Feature:

    LOW CAPACITANCE, HIGH RELIABILITY

  • Breakdown Voltage-Max:

    8 V

  • Breakdown Voltage-Min:

    6 V

  • Case Connection:

    ANODE

  • Configuration:

    COMMON ANODE, 5 ELEMENTS

  • Diode Element Material:

    SILICON

  • Diode Type:

    TRANS VOLTAGE SUPPRESSOR DIODE

  • JESD-30 Code:

    S-PDSO-N6

  • JESD-609 Code:

    e4

  • Moisture Sensitivity Level:

    1

  • Non-rep Peak Rev Power Dis-Max:

    70 W

  • Number of Elements:

    5

  • Number of Terminals:

    6

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity:

    UNIDIRECTIONAL

  • Qualification Status:

    Not Qualified

  • Rep Pk Reverse Voltage-Max:

    5 V

  • Surface Mount:

    YES

  • Technology:

    AVALANCHE

  • Terminal Finish:

    NICKEL PALLADIUM GOLD

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

DMF05LCFLP-7 Frequently Asked Questions (FAQs)

  • The recommended PCB footprint for the DMF05LCFLP-7 is a 2x2 array of 0.5mm diameter pads with a 1.5mm pitch, and a thermal pad in the center.
  • To ensure reliable operation in high-temperature environments, ensure that the device is properly mounted on a heat sink, and that the thermal pad is connected to a copper plane on the PCB to dissipate heat effectively.
  • The maximum allowable voltage for the DMF05LCFLP-7 is 5.5V, and it is recommended to operate the device within the specified voltage range to ensure reliable operation.
  • To handle ESD protection for the DMF05LCFLP-7, ensure that the device is handled in an ESD-protected environment, and that the PCB is designed with ESD protection in mind, such as using ESD-protection diodes or resistors.
  • The recommended storage condition for the DMF05LCFLP-7 is in a dry, cool place, away from direct sunlight, and in its original packaging or an anti-static bag.
