DMHC4035LSD-13 - Diodes Incorporated

Description: MOSFET H-Bridge 40V 4.5A/3.7A SOIC8 Diodes Inc DMHC4035LSD-13 Quad N/P-channel MOSFET Transistor, 8-Pin SOIC

Download DMHC4035LSD-13 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
DMHC4035LSD-13 - Diodes Incorporated PCB footprint - Small Outline Packages - Small Outline Packages - SO-8
click to zoom
3D Models
DMHC4035LSD-13 - Diodes Incorporated  - 3D model - Small Outline Packages - SO-8
click to zoom

DMHC4035LSD-13 Details

  • Manufacturer Part Number:

    DMHC4035LSD-13

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOP-8

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    5

  • Configuration:

    BRIDGE, 4 ELEMENTS WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    40 V

  • Drain Current-Max (ID):

    4 A

  • Drain-source On Resistance-Max:

    0.045 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    38.7 pF

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    4

  • Number of Terminals:

    8

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity/Channel Type:

    N-CHANNEL AND P-CHANNEL

  • Power Dissipation-Max (Abs):

    1.5 W

  • Pulsed Drain Current-Max (IDM):

    25 A

  • Reference Standard:

    MIL-STD-202

  • Surface Mount:

    YES

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    GULL WING

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

DMHC4035LSD-13 Frequently Asked Questions (FAQs)

  • The recommended PCB footprint for the DMHC4035LSD-13 is a standard SOT23-6 package with a 1.8mm x 1.4mm body size. The datasheet provides a recommended land pattern and soldering guidelines.
  • To ensure proper biasing, follow the recommended operating conditions and biasing circuits provided in the datasheet. Typically, a voltage regulator or a resistive divider network is used to set the input voltage and current limits.
  • The DMHC4035LSD-13 is rated for operation from -40°C to 125°C. However, the device's performance and reliability may degrade if operated at extreme temperatures for extended periods.
  • Yes, the DMHC4035LSD-13 is suitable for high-reliability and automotive applications. It meets the requirements of AEC-Q100 and is manufactured using automotive-grade processes.
  • To prevent electrostatic discharge (ESD) damage, handle the DMHC4035LSD-13 with ESD-protective equipment, such as wrist straps, mats, and bags. Follow proper ESD handling procedures to prevent damage during storage, handling, and assembly.
