DMN3016LDN-7 - Diodes Incorporated

DMN3016LDN-7 Details

• Manufacturer Part Number:

  DMN3016LDN-7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  V-DFN3030-8, 8 PIN

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  24 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  24 mJ

• Case Connection:

  DRAIN

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  30 V

• Drain Current-Max (ID):

  7.3 A

• Drain-source On Resistance-Max:

  0.02 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  82 pF

• JESD-30 Code:

  S-PDSO-N8

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  1.6 W

• Pulsed Drain Current-Max (IDM):

  45 A

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
