DMT2-200-3.8L - COILCRAFT

DMT2-200-3.8L Details

• Manufacturer Part Number:

  DMT2-200-3.8L

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  6.7

• Construction:

  Rectangular

• DC Resistance:

  0.19 Ω

• Inductance-Nom (L):

  200 µH

• Inductor Application:

  RF INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e2

• Lead Diameter:

  1.32 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  40.6 mm

• Package Length:

  40.6 mm

• Package Style:

  PCB Mount

• Package Width:

  22.9 mm

• Rated Current-Max:

  3.8 A

• Self Resonance Frequency:

  2.07 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver (Sn/Ag)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.01575 MHz
