DPAM-15-07.0-S-8-2-A-K - SAMTEC

Description: Conn Differential Pair Array PL 90Signal/30Ground POS 1.08mm Solder ST SMD Tray

Download DPAM-15-07.0-S-8-2-A-K Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DPAM-15-07.0-S-8-2-A-K - SAMTEC - PCB symbol
click to zoom
PCB Footprints
DPAM-15-07.0-S-8-2-A-K - SAMTEC PCB footprint - Other - Other - DPAM-15-07.0-S-8-2-A-K-7
click to zoom
3D Models
DPAM-15-07.0-S-8-2-A-K - SAMTEC - 3D model - Other - DPAM-15-07.0-S-8-2-A-K-7
click to zoom

DPAM-15-07.0-S-8-2-A-K Details

  • Manufacturer Part Number:

    DPAM-15-07.0-S-8-2-A-K

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    ROHS COMPLIANT

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.69.40.40

  • Manufacturer:

    Samtec Inc

  • YTEOL:

    0

  • Connector Type:

    BOARD CONNECTOR

  • Contact Finish Mating:

    TIN OVER NICKEL

  • Contact Finish Termination:

    Tin (Sn) - with Nickel (Ni) barrier

  • Contact Gender:

    MALE

  • Contact Material:

    NOT SPECIFIED

  • DIN Conformance:

    NO

  • Filter Feature:

    NO

  • IEC Conformance:

    NO

  • JESD-609 Code:

    e3

  • MIL Conformance:

    NO

  • Mating Information:

    MULTIPLE MATING PARTS AVAILABLE

  • Mixed Contacts:

    NO

  • Mounting Style:

    RIGHT ANGLE

  • Mounting Type:

    BOARD

  • Number Of Connectors:

    ONE

  • Number of Rows Loaded:

    8

  • Option:

    GENERAL PURPOSE

  • Terminal Pitch:

    2.16 mm

  • Termination Type:

    SOLDER

  • Total Number of Contacts:

    108

DPAM-15-07.0-S-8-2-A-K Frequently Asked Questions (FAQs)

  • The recommended torque for the screw locks is 0.5-1.5 in-lbs (0.056-0.169 Nm) according to Samtec's application notes.
  • Yes, the DPAM-15-07.0-S-8-2-A-K connector is designed to withstand high-vibration environments. Samtec recommends following their guidelines for vibration testing and ensuring proper screw torque to ensure reliable connections.
  • The maximum operating temperature for the DPAM-15-07.0-S-8-2-A-K connector is 125°C (257°F) according to Samtec's datasheet.
  • The DPAM-15-07.0-S-8-2-A-K connector is not sealed and is not intended for use in humid or wet environments. If exposure to moisture is a concern, consider using a sealed or waterproof connector or applying additional protection measures.
  • The mating cycle life of the DPAM-15-07.0-S-8-2-A-K connector is 500 cycles minimum according to Samtec's datasheet.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

DPAM-15-07.0-S-8-2-A-K Overview

Use the download button to access the DPAM-15-07.0-S-8-2-A-K schematic symbol, PCB footprint, and 3D model.
