DPG10I200PM - LITTELFUSE

DPG10I200PM Details

• Manufacturer Part Number:

  DPG10I200PM

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  5.87

• Additional Feature:

  FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE

• Application:

  FAST SOFT RECOVERY

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.98 V

• JEDEC-95 Code:

  TO-220AC

• JESD-30 Code:

  R-PSFM-T2

• Non-rep Pk Forward Current-Max:

  140 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  10 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  200 V

• Reverse Recovery Time-Max:

  0.035 µs

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
