DS1040-10RN - Connfly

DS1040-10RN Details

• Manufacturer Part Number:

  DS1040-10RN

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  Ningbo connfly electronic CO LTD

• Actuator Color:

  WHITE

• Actuator Material:

  PLASTIC

• Actuator Type:

  SLIDE TYPE

• Body Breadth:

  0.216 mm

• Body Color:

  RED

• Body Height:

  0.39 mm

• Body Length or Diameter:

  25.4 mm

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  .1A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  2000 Cycle(s)

• Housing Material:

  PLASTIC

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switch Sections:

  10

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  16

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Length:

  0.13 inch

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
