DS1265AB-70IND+ - Analog Devices

DS1265AB-70IND+ Details

• Manufacturer Part Number:

  DS1265AB-70IND+

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  N/A

• Package Description:

  0.740 INCH, ROHS COMPLIANT, DIP-36

• Pin Count:

  36

• Manufacturer Package Code:

  N/A

• Country Of Origin:

  Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

• ECCN Code:

  3A991.b.2.a

• HTS Code:

  8542.32.00.41

• Date Of Intro:

  2002-11-06

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Access Time-Max:

  70 ns

• JESD-30 Code:

  R-XDMA-P36

• JESD-609 Code:

  e3

• Memory Density:

  8388608 bit

• Memory IC Type:

  NON-VOLATILE SRAM MODULE

• Memory Width:

  8

• Number of Functions:

  1

• Number of Terminals:

  36

• Number of Words:

  1048576 words

• Number of Words Code:

  1000000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  1MX8

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIP

• Package Equivalence Code:

  DIP36,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Parallel/Serial:

  PARALLEL

• Qualification Status:

  Not Qualified

• Standby Current-Max:

  0.0002 A

• Supply Current-Max:

  0.085 mA

• Supply Voltage-Max (Vsup):

  5.25 V

• Supply Voltage-Min (Vsup):

  4.75 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL
