DSC400-0111Q0029KE2T - Microchip

DSC400-0111Q0029KE2T Details

• Manufacturer Part Number:

  DSC400-0111Q0029KE2T

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-20

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  7.12

• Additional Feature:

  REPLACED EXTERNAL CLOCK/CRYSTAL AS MEMS INTERNAL CLOCK

• JESD-30 Code:

  R-XQCC-N20

• Length:

  5 mm

• Number of Terminals:

  20

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Output Clock Frequency-Max:

  460 MHz

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC20,.12X.2,20

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  0.9 mm

• Supply Current-Max:

  44 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  2.25 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  3.2 mm

• uPs/uCs/Peripheral ICs Type:

  CLOCK GENERATOR, MEMS
