DSP1-L2-DC5V-F - Panasonic

DSP1-L2-DC5V-F Details

• Manufacturer Part Number:

  DSP1-L2-DC5V-F

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  5.5

• Additional Feature:

  RELEASE TIME WITHOUT DIODE

• Body Breadth:

  11 mm

• Body Height:

  10.5 mm

• Body Length or Diameter:

  20.2 mm

• Coil Current(DC)-Max:

  0.06 A

• Coil Operate Voltage(DC):

  4 V

• Coil Power:

  300 mW

• Coil Release Voltage(DC):

  4 V

• Coil Resistance:

  83 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  5A@380VAC

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  5 A

• Contact (DC) Max Rating R Load:

  5A@125VDC

• Contact Voltage(AC)-Max:

  380 V

• Contact Voltage(DC)-Max:

  125 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  20.2mm x 11mm x 10.5mm

• Reference Standard:

  CSA; TUV; UL

• Relay Action:

  LATCHED

• Relay Function:

  DPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  5 ms

• Sealing:

  WATER PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER
