DVHF2812S - VPT

DVHF2812S Details

• Manufacturer Part Number:

  DVHF2812S

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan, USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  VPT Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  50 V

• Input Voltage-Min:

  15 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-XDMA-P8

• Length:

  37.08 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  1.67 A

• Output Voltage-Max:

  12.18 V

• Output Voltage-Min:

  11.82 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIP

• Package Equivalence Code:

  DIP8/10,.8,300/200

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Qualification Status:

  Not Qualified

• Screening Level:

  MIL-PRF-38534

• Seated Height-Max:

  8.38 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  MILITARY

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  5.08 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  20 W

• Trim/Adjustable Output:

  NO

• Width:

  28.7 mm
