DXTN3C100PSQ-13 - Diodes Incorporated

DXTN3C100PSQ-13 Details

• Manufacturer Part Number:

  DXTN3C100PSQ-13

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Date Of Intro:

  2018-07-10

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  4

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  3 A

• Collector-Emitter Voltage-Max:

  100 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  10

• JESD-30 Code:

  R-PDSO-F5

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  3

• Number of Elements:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, 13 INCH

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  2.5 W

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  140 MHz

• VCEsat-Max:

  0.33 V
