DXTP22040DFG-7 - Diodes Incorporated

DXTP22040DFG-7 Details

• Manufacturer Part Number:

  DXTP22040DFG-7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  4

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  2 A

• Collector-Base Capacitance-Max:

  12 pF

• Collector-Emitter Voltage-Max:

  40 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  120

• JESD-30 Code:

  S-PDSO-F8

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  PNP

• Power Dissipation-Max (Abs):

  3.4 W

• Reference Standard:

  MIL-STD-202

• Surface Mount:

  YES

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  120 MHz

• VCEsat-Max:

  0.6 V
