E35SE24006PDPG - Delta Electronics

E35SE24006PDPG Details

• Manufacturer Part Number:

  E35SE24006PDPG

• Part Life Cycle Code:

  Active

• Package Description:

  1/8 BRICK PACKAGE-8

• ECCN Code:

  EAR99

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  7.3

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC, EN, UL, CSA

• Efficiency (Main Output):

  92.2%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-XDMA-P8

• Length:

  58.4 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  6 A

• Output Voltage-Max:

  28.8 V

• Output Voltage-Min:

  19.2 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.0813 Vrms

• Seated Height-Max:

  14 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  144 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.535 s

• Width:

  22.8 mm
