E48SC32009NRDH - Delta Electronics

E48SC32009NRDH Details

• Manufacturer Part Number:

  E48SC32009NRDH

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/8 brick package-15

• ECCN Code:

  EAR99

• Date Of Intro:

  2019-06-19

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CSA, IEC, EN, UL

• Efficiency (Main Output):

  95%

• Input Voltage-Max:

  72 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XXMA-P15

• Length:

  58.4 mm

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  15

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  9.4 A

• Output Voltage-Max:

  35 V

• Output Voltage-Min:

  16 V

• Output Voltage-Nom:

  32 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE

• Ripple Voltage (Main Out):

  0.053025 Vrms

• Screening Level:

  IEC/EN/UL 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  300 W

• Trim/Adjustable Output:

  YES

• Width:

  22.8 mm
